Yanmar 62.5″ Disc Harrow

Description

Yanmar YDH105 62.5-Inch Disc Harrow for Sub-Compact Tractors

The YDH105 is a compact disc harrow with sixteen 14-inch notched blades across a 62.5-inch cultivation width. It breaks up plowed ground, chops crop residue and prepares food plots, and it is sized for smaller tractors from about 18 to 32 HP.

Blades and Frame

Notched blades cut through residue and hard clods more aggressively than smooth blades. Blade spacing is 7.5 inches, and the harrow weighs about 407 pounds. The Category 0 hitch spacing matches the smallest tractors, so owners of larger compact tractors should confirm fit before ordering. Adjusting the gang angle controls how aggressively the blades throw soil.

• Number of Blades: 16
• Hitch: Category 0
• Suggested tractor size: 18 to 32 HP
• Approximate weight: 407 lbs
• Blades: sixteen 14-inch notched

Using a Disc After Plowing

Two passes at right angles break clods more evenly than one pass in a single direction. Starting with the gangs at a shallow angle and increasing it only if the soil is not breaking up avoids overworking a small tractor, and greasing the bearings after washing keeps water out of them.

Where It Fits

The YDH105 suits sub-compact and small compact tractors working gardens and food plots. The 75-inch YDH206 and 85-inch YDH307 are built for larger tractors with standard Category 1 hitches.
